MWIR Motorized IR Lens

Motorized

Overview

Our MWIR Motorized Lens is designed for enterprise-grade thermal imaging applications that demand precision, flexibility, and scalable supply. These lenses cover the mid-wave infrared (3–5 µm) spectrum and feature motorized zoom and focus control, making them ideal for dynamic environments and automated systems.

Enterprise users include:

OEMs integrating motorized thermal lenses into drones, vehicles, or industrial machinery.
System integrators deploying advanced surveillance or inspection networks.
Industrial inspection firms monitoring high-temperature processes, machinery, and energy infrastructure.
Security and firefighting agencies needing rapid zoom and focus adjustments in real-world conditions.
Energy & utility operators inspecting substations, pipelines, or remote equipment.

Key Advantages for Enterprise Buyers

Motorized zoom & focus: Adjustable FOV and precise focus for changing inspection distances or surveillance needs.
High MWIR transmission: Optimized coatings for 3–5 µm spectrum, ensuring clear imaging and accurate thermal readings.
OEM & integration-ready: Flexible mounts, standard interfaces, and mechanical designs for smooth integration.
Customizable options: Focal length, F/#, zoom ratio, and housing tailored to enterprise applications.
Scalable production: Reliable fulfillment for multi-site deployments, OEM assembly lines, or fleet-level procurement.

Typical Specifications (Reference)

Item	Typical Value / Options
Lens type	MWIR Motorized Lens
Spectral range	3–5 µm (MWIR)
Motorized zoom	2×–10× (configurable)
Focal length	Customizable (e.g., 12 mm–150 mm)
F/#	f/1.0 – f/2.0
Field of view	Variable, motorized
Mount	C-mount / custom OEM mount
Transmission	>90% typical MWIR
Operating temperature	-40°C to +70°C
Housing	Aluminum alloy, optional IP rating
Coatings	MWIR AR coating, custom coatings available

Applications for Enterprise Users

Industrial Inspection: Zoom in on high-temperature machinery, turbines, pipelines, and electrical equipment.
Drone & UAV OEMs: Motorized zoom for aerial surveillance, mapping, and monitoring applications.
Security & Surveillance Integrators: Adjust focus and FOV for perimeter protection, crowd management, and infrastructure monitoring.
Firefighting & Emergency Response: Quickly adjust zoom to identify hotspots, detect fire spread, and guide operations.
OEMs & System Integrators: Integrate into robotics, vehicles, and automated inspection systems for enterprise-grade solutions.

Enterprise OEMs, system integrators, industrial inspection providers, and public safety agencies: contact Beijing IRLENS Sales & Procurement team today for a quote, sample, or technical consultation. Ensure scalable supply, high-precision MWIR optics, and motorized zoom control for your next thermal imaging deployment.

Classification

MWIR Lens for Cooled Camera

LWIR Lens for Uncooled Camera

LWIR Lens for Cooled Camera

Off-axis Collimator

Tags

MWIR Lens Mid-wave lR lenses lmaging Lenses for Cooled Cameras

We have a professional after-sales team, always focuses on customer needs, and provides a full range of efficient services. It is easy to solve the problem for manufacturing company.

50mm F1.5 MWIR Motorized Lens

Inquiry

180mm F2 MWIR Motorized Lens

Inquiry

180mm F1.8 MWIR Motorized Lens

Inquiry

Application Scenario

Aerospace Detection

In the aerospace field, infrared lenses play an indispensable role. Airborne night vision is one of its important applications. In addition, in satellite remote sensing, infrared lenses can penetrate clouds and obtain information such as surface temperature and vegetation cover, contributing to agricultural monitoring, geological exploration, and more. It also can detect the infrared radiation of celestial bodies like asteroids and comets.

Security Monitoring

Infrared lens can operate in low-light or even complete darkness, using the infrared radiation emitted by objects for imaging. Moreover, they are not affected by severe weather such as heavy rain and thick fog, and can penetrate these obstacles to capture targets, ensuring the stability of monitoring, greatly enhancing the reliability and comprehensiveness of security monitoring.

Industrial Surveillance

Since different materials and components in industrial settings have distinct infrared emission characteristics, these lenses enable the detection of thermal anomalies. In the manufacturing of mechanical parts, infrared lenses can detect areas with abnormal heat distribution during the production process, helping to ensure product quality and prevent defects.

Fire-fighting and Rescue

At the fire scene, infrared lenses can penetrate smoke and flames and clearly display the location of trapped persons, the direction of fire spread, and the ignition point. This helps firefighters quickly formulate rescue plans, improve search and rescue efficiency, and reduce casualties and property losses. In addition, it can also be used for fire hazard investigation to discover potential fire risks such as overheating of electrical equipment and accumulation of flammable materials in advance.

Gas Surveillance

Infrared lenses are the key components in gas detection instruments, enabling the precise identification and quantification of various industrial gases. Many industrial gases have unique absorption characteristics in the infrared spectrum.

Driving Night Vision

These lenses are designed to capture infrared radiation, which is invisible to the human eye but emitted by objects based on their heat signatures. They focus this infrared light onto an image sensor, converting it into a visible image that can be displayed on a monitor inside the vehicle. This enables drivers to perceive potential obstacles on the road much earlier than with normal vision, providing them with more reaction time and significantly enhancing driving safety in low-light conditions.
